Detailed description

Product Structure:
* Eight-core pair stranded conductor: CAT8 network cable
4P multi-stranded bare copper 26AWG, OD: 6.0mm
4P multi-stranded bare copper 28AWG, OD: 6.0mm
4P multi-stranded bare copper 32AWG, OD:2.2* 7.2mm flat cable
LSZH Oxygen free copper (99.99% purity), multiple stranded wire
* Insulation: foaming PE
* Sheath: imported environmental protection polyvinyl chloride PVC ( RoHS CM CMR CMP or LSZH optional)

Product Features:
* Insertion times: ≥1000 times
* Supports configuration of T568A (ISDN) and T 568B (ALT) pins;
* Transmission rate up to 40Gbps
* Provide up to 2000MHz operating frequency (bandwidth)
* RJ45 shielded crystal head, shielding layer nickel plated copper shell + gold plated copper shell, crystal head reed surface gold plated,
Ensure very good contact and signal transmission performance;
* Gradual force principle of elongated sheath, anti-slip tensile, to ensure a certain bending radius;
* Full automatic machine riveting and pressing;
* Made by gluing process, the wire seal is not oxidized;
* Provide different colors, length of jumper, cable management is easier;
* 7 strands of multi-strand copper conductor, PVC sheath, soft and comfortable cable;
* Provide various lengths: 1m to 20m and user specified length, PVC sheath can be provided with a variety of colors (various lengths up to 10,000 meters in total);
* Meet or exceed ANSI/TIA/EIA-568-C-2, CSAT529-95 specifications for connection hardware;

Product Application:
* Home local area network and cabling network in the computer room
* Structured wiring for data transmission, transmission of digital and voice and video signals;
* Multi-user telecom socket;
* centralized joint point;
* Support all applications designed for CAT8 (class 8) cabling systems.
