Detailed description

Applications:

 10Base-T,10Base-T4

Standards:

ISO/IEC11801,ANSI/TIA/EIA-568-B(International standards: ISO/IEC11801,ANSI/TIA/EIA-568-B)

 Features of Product

 Comply with the ROHS Standards;

  Many kinds of sheath can be designed

  according to the environmental demands;

  Special design for trunk voice transmission;

  Clear labels be convenient for fixing.

parameters:

Notes: PE- Polyethylene; PVC- Polyvinyl chloride; LSZH-Low Smoke Zero Halogen; Grades of PVC Fire Resistance CMX,CM,CMR and CMP

  Physical and Electrical Characteristics

Impedance: 1-16MHz  100±15Ω

 Max. Mutual Capacitance:  6.6nF/100m

 Max. Unbalanced DC resistance: 2.5%

 Max. Differential phase delay: 45nF/100m

 Permitted bend radius: 10 times diameter of the cable

  Fixing temperature: 0~+55°C

  Operating temperature: -20°C~+60°C

  Max. Tension: 80N

  Min. Dielectric Strength Between Conductors: 1.0kV/min

Transmission Performance
