Detailed description
UTP CAT5 HSYZ5e
outdoor flame resistant horizontal symmetrical twisted pair unshielded cable for digital communication
UTP category 5e
| cable type | flame resistant unshielded twisted network cable |
| description |
LSZH PVC jacket |
| operation temperature | -20~+60°C |
| applications |
*10 Base-T *100 Base-T4 *100 Base-TX *100 Base-VG-ANYLAN *155 Mbps ATM *622 Mbps ATM |
| standards |
*ISO/IEC 11801 *ANSI/TIA/EIA-568-C *YD/T 1019-2013 *UL 444 *IEC 61156 |
| material instructions |
*conductor : 24AWG copper *insulation : solid HDPE or skin-foam-skin PE *sheath : flame resistant LSZH PVC |
| characteristics |
*more bandwidth excess than 100 MHz standard required *comply with ROHS standard *the products of special outer sheath or purpose can be designed according to customer's demands *excellent fire resistant property |
| physical electrical characteristics |
*D.C resistance (max) : 9.5 Ω/100 m at 20 celsius degree *mutual capacitance (max) : 5.6nF/100m *dielectric strength between conductors (min): 2.5kv/2s *impedance : 1-100 MHz 100±15Ω *differential phase delay (max) : 30ns/100m *permitted bend radius : over 8 times diameter of the cable |
