Cat6

Packaging & Delivery

Packaging Details: 1. Pull out pox 305m/pull out box, 2boxes/outer carton.
2. Plastic reel + Carton
3. Wooden reel + Carton
4. As client' s request .

Product Description

High-Performance data cable ,application structured cabling, CCTV system , Alarm system , Telecom project etc.
Exceeds TIA/EIA-568B.2,ISO/IEC 11801 , ETL listed .
100Base-TX,100Base-T2 and 100Base-T4 standard.
Can be used for voice, integrated service data network (ISDN).
Long transmission distance, small transmission loss, wear resistance, resistance to pressure.

Model	utp cat6 cable
Conductor Size	24AWG
Conductor Size	0.45mm/0.48mm/0.49mm/0.5mm/0.51mm
Conductor Material	CCA/CCU/BC
Nuber Of Conductor	4P
Shiled	UTP/FTP/STP/SFTP
Flammability Grade:	CMP,CMX,CM,CMG,MPG,CMR,MPR
Indoor / Outdoor	Single jacket/Double jacket
Insulation Material	PE,HDPE,LSZH PE
Insulation Thickness	0.91mm
Jacket Material	PVC, ROHS PVC, LSZH PVC
Outer Jacket Thickness	5.2mm
DC Resistance(Max.)	9.5 Ohm/100m
DC Resistance Imbalance	2.50%
Working Capacitance(Max.)	5.4nF/100m
Insulation Resistance	10000 MOhm.km
Transmission Velocity	65%
Operating Temperation	-40 °C - +75 °C
PVC Jacket Color	As client's request.
Marking On Jacket	On your request (Print your brand)
