Detailed description

Product Structure:
* 4P 8core twisted pair conductor:
4P multi-strand copper 24AWG, wire OD: 5.5mm
4P multi-strand copper 26AWG, wire OD: 5.3mm
4P multi-strand copper 28AWG, wire OD: 5.1mm

* Insulation: HD-PE
* Sheath: PVC (RoHS LSZH CM CMR CMP rate optional)

Product Features:
* Supports configuration of T568A (ISDN) and T 568B (ALT) pins;
* the transmission rate is 100Mbps
* The crystal head reed surface is gilded to ensure very good contact and signal transmission performance;
* Gradual force principle of elongated sheath, anti-slip tensile, to ensure a certain bending radius;
* Full automatic machine riveting and pressing;
* Made by gluing process, the wire seal is not oxidized;
* Provide different colors, length of jumper, cable management is easier;
* 7 strands of multi-strand copper conductor, PVC sheath, soft and comfortable cable;
* Various lengths: 1m to 70m and user specified length, PVC sheath can be provided in a variety of colors (various lengths up to 10,000 meters in total);
* Meet or exceed ANSI/TIA/EIA-568-B.S-2, CSAT529-95 specifications for five categories of connection hardware;

Product Application:
* Home local area network and cabling network in the computer room
* Structured wiring for data transmission, transmission of digital and voice and video signals;
* Multi-user telecom socket;
* centralized joint point;
* Support all applications designed for super Class 5e cabling systems.
