Detailed description

Product Structure:

* 4P 8core twisted pair conductor:
4P multi-strand copper 24AWG + ground wire + Mylar + aluminum foil +braiding net. Wire OD: 5.8mm±0.2mm

4P multi-strand copper 26AWG  + ground wire + Mylar + aluminum foil. wire OD: 5.6mm±0.2mm

4P multi-strand copper 28AWG  + ground wire + Mylar + aluminum foil. wire OD: 5.4mm±0.2mm


* Insulation: HD-PE

* Sheath: PVC (RoHS LSZH CM CMR CMP rate optional)

Product Features:

* Supports configuration of T568A (ISDN) and T 568B (ALT) pins;

* the transmission rate is 100Mbps

* Cat5e RJ45 shielded crystal head The crystal head reed surface is gilded, ensuring very good contact and signal transmission performance;

* Gradual force principle of elongated sheath, anti-slip tensile, to ensure a certain bending radius;

* Full automatic machine riveting and pressing;

* Made by gluing process, the wire seal is not oxidized;

* Provide different colors, length of jumper, cable management is easier;

* 7 strands of multi-strand copper conductor, PVC sheath, soft and comfortable cable;

* Various lengths: 1m to 70m and user specified length, PVC sheath can be provided in a variety of colors (various lengths up to 10,000 meters in total);

* Meet or exceed ANSI/TIA/EIA-568-B.S-2, CSAT529-95 specifications for five categories of connection hardware;

Product Application:

* Home local area network and cabling network in the computer room

* Structured wiring for data transmission, transmission of digital and voice and video signals;

* Multi-user telecom socket;

* centralized joint point;

* Support all applications designed for super Class 5e CAT5E cabling systems.
